Benefits and Features

Premium drive tire applicable for regional paved road
Wide tread promises even pressure while running on road and improves long life tread wear
Special tread compound and CAD tire carcass help to guarantee long tire life and better retreadablillity
Extra deep grooves with central longitude ribs provide perfect traction with robust open shoulder blocks

Size	LR/PR	Tread Depth (32ND)	Service Index	Standard Rim	Overall Diameter (inch)	Section Width (inch)	Max. Load Capacity at Cold Inflation Pressure				Revs per Mile	Static Loaded Radius (inch)
							Single		Dual
							(LBS)	(PSI)	(LBS)	(PSI)
235/75R17.5	H/16	21	143/141J	6.75	31.3	9.1	6005	128	5675	128	662	14.6
225/70R19.5	G/14	19	128/126M	6.75	31.9	8.9	3970	110	3750	110	651	15.0
245/70R19.5	G/14	20	133/131M	7.50	33.0	9.8	4540	110	4300	110	629	15.5
245/70R19.5	H/16	20	136/134M	7.50	33.0	9.8	4940	120	4675	120	629	15.5
265/70R19.5	G/14	20	137/134M	7.50	34.1	10.3	5070	110	4675	110	609	16.0
265/70R19.5	H/16	20	140/138M	7.50	34.1	10.3	5510	112	5200	112	609	16.0
11R22.5	G/14	28	144/142L	8.25	41.9	11.0	6175	105	5840	105	496	19.5
11R 22.5	H/16	28	146/143L	8.25	41.9	11.0	6610	120	6005	120	496	19.5
295/75R22.5	G/14	28	144/141L	9.00	40.2	11.7	6175	110	5675	110	520	18.8
11R24.5	G/14	28	146/143L	8.25	43.9	11.0	6610	105	6005	105	473	20.5
11R24.5	H/16	28	149/146L	8.25	43.9	11.0	7160	120	6610	120	473	20.5
285/75R24.5	G/14	28	144/141L	8.25	41.6	11.1	6175	110	5675	110	499	19.5
